| Item |
Specifications |
| Measurement object |
Heat flow and temperature |
| Measuring range |
Heat flow: 0 - ±99999 W/m2 or kcal/m2h |
| Temperature: Chromel-Alumel thermocouple -200 ~
1200°C |
| Temperature: Copper-Constantan thermocouple -200 ~
400°C |
| Selectable units |
Heat flow: W/m2,
kcal/m2h or Temperature: °C |
| Sampling cycle |
Selectable from 1, 2, 5, 10, 30, 60, 120, 300 or 600
seconds |
| Display update |
Synchronized with sampling cycle |
| Operation function |
Various operations between channels are possible. |
| A and B Constants |
A and B sensor constants can be input by key entry. |
| Number of sensors |
‘A’ constant type sensor: Max. 12 |
| ‘A, B’ constant type sensor: Max. 5 |
| Display |
Trend graph or bar graph in 16 colors |
| Data memory |
6-channel measurement can continuously store data for
27 hours with 1-sec data saving cycle. |
| External memory device |
3.5-inch floppy disk drive |
| External communication |
Ethernet (10BASE-T): 1-channel Web server function |
| E-mail communication |
| Ambient conditions |
Temperature: 0 - 40°C
Humidity: 20 - 80%RH (subject no condensation) |
| Power source |
Rechargeable battery (with a standard AC adapter) |
| Dimension |
152(W) x 240(D) x 225(H) (mm) |
| Weight |
Approx. 4kg |
| Accessories |
| AC adapter |
---------- |
One |
| Data Capture Software for PC |
---------- |
One |
| Operation manual |
---------- |
One |
|
| Options |
-Connecting cable for PC
-Carrying case |
